Yamaha CIS SWP1 Series L2 Gigabit Dante Switch
Product Details
Complex network switch setup that was previously better left to an IT technician can now be easily accomplished by anyone. A simple switch setting is all it takes to optimize SWP1 series network switches for Dante operation, and a dedicated computer application called Yamaha LAN Monitor provides “network visibility” for comprehensive monitoring and control.
Yamaha first entered the network device business in 1995, and has grown to hold a significant share of Japan’s small to medium enterprise and SOHO network market. Yamaha gigabit L2 switches that could be linked to Yamaha routers/firewalls were introduced in 2011, with features that significantly reduced the network setup, maintenance, and management workload.
20 years later audio networking has become one of the fastest growing, most highly valued technologies in the live sound and pro audio fields. An expanding range of Dante capable Yamaha products, including the highly regarded CL series digital mixing consoles, continues to lead the way. SWP1 series network switches are a solution the pro audio market has been waiting for, offering an ideal balance of IT and pro audio know-how that only Yamaha can provide.
The SWP1 series makes audio network setup, monitoring, and operation easier and more convenient than ever before.
Specifications
| SWP1-16MMF | SWP1-8MMF | SWP1-8 | ||
|---|---|---|---|---|
| Number of LAN ports (1000BASE-T/100BASE-TX/10BASE-T, etherCON connector) | 12 | 8 | 8 | |
| Number of LAN ports (1000BASE-T/100BASE-TX/10BASE-T, RJ-45 connector) | 4 | - | - | |
| Number of SFP ports (1000BASE-SX, opticalCON connector) | 2 (1 optical module is installed as standard) | 2 (1 optical module is installed as standard) | 2 (optical modules are not installed as standard) | |
| Console port | 1 (RJ-45) | 1 (RJ-45) | 1 (RJ-45) | |
| Automatic negotiation | Available | Available | Available | |
| Auto MDI/MDI-X | Available | Available | Available | |
| Switching capacity | 36 Gbit/s | 20 Gbit/s | 20 Gbit/s | |
| Throughput | 27 Mpps | 15 Mpps | 15 Mpps | |
| Maximum number of MAC addresses | 16,384 | 16,384 | 16,384 | |
| Frame buffer | 1024 kB | 1024 kB | 1024 kB | |
| VLAN | Port VLAN, Tag VLAN (IEEE802.1Q), Private VLAN | Port VLAN, Tag VLAN (IEEE802.1Q), Private VLAN | Port VLAN, Tag VLAN (IEEE802.1Q), Private VLAN | |
| Maximum number of VLANs | 256 (VLAN ID 1-4,094) *VLAN ID 1 is the default VLAN ID. | 256 (VLAN ID 1-4,094) *VLAN ID 1 is the default VLAN ID. | 256 (VLAN ID 1-4,094) *VLAN ID 1 is the default VLAN ID. | |
| IP multicast | IGMP Snooping (v1/v2/v3) | IGMP Snooping (v1/v2/v3) | IGMP Snooping (v1/v2/v3) | |
| QoS | 8 egress queues, Policy-based QoS, Remarking (CoS, ToS, DSCP), Scheduling (SP, WRR) | 8 egress queues, Policy-based QoS, Remarking (CoS, ToS, DSCP), Scheduling (SP, WRR) | 8 egress queues, Policy-based QoS, Remarking (CoS, ToS, DSCP), Scheduling (SP, WRR) | |
| Flow control | IEEE802.3x (Full-duplex), back pressure (Half-duplex) | IEEE802.3x (Full-duplex), back pressure (Half-duplex) | IEEE802.3x (Full-duplex), back pressure (Half-duplex) | |
| Support functions | Storm control, HOL blocking prevention, Loop detection, ACL, SNMP agents, Link aggregation (IEEE 802.3ad LACP, Static), Spanning tree (STP*, RSTP*, MSTP), Port mirroring, Port shutdown, Link speed down shift, Packet counter, Power saving mode (IEEE802.3az EEE; Disabled in DANTE mode), DHCP client, Logging, Firmware download via TFTP/HTTP, Config file download via TFTP *STP and RSTP are supported via downward compatibility of MSTP. | Storm control, HOL blocking prevention, Loop detection, ACL, SNMP agents, Link aggregation (IEEE 802.3ad LACP, Static), Spanning tree (STP*, RSTP*, MSTP), Port mirroring, Port shutdown, Link speed down shift, Packet counter, Power saving mode (IEEE802.3az EEE; Disabled in DANTE mode), DHCP client, Logging, Firmware download via TFTP/HTTP, Config file download via TFTP *STP and RSTP are supported via downward compatibility of MSTP. | Storm control, HOL blocking prevention, Loop detection, ACL, SNMP agents, Link aggregation (IEEE 802.3ad LACP, Static), Spanning tree (STP*, RSTP*, MSTP), Port mirroring, Port shutdown, Link speed down shift, Packet counter, Power saving mode (IEEE802.3az EEE; Disabled in DANTE mode), DHCP client, Logging, Firmware download via TFTP/HTTP, Config file download via TFTP *STP and RSTP are supported via downward compatibility of MSTP. | |
| DIP switches | CONFIG, VLAN PRESET | CONFIG, VLAN PRESET | CONFIG, VLAN PRESET | |
| Indicators | Front: POWER, LED MODE×4, PORT×16×2*, SFP×2 *The LED MODE button allows the PORT lamps to be switched between indicating LINK/ACT-SPEED, STATUS, or VLAN. | Front: POWER, LED MODE×4, PORT×8×2*, SFP×2 *The LED MODE button allows the PORT lamps to be switched between indicating LINK/ACT-SPEED, STATUS, or VLAN. | Front: POWER, LED MODE×4, PORT×8×2*, SFP×2 *The LED MODE button allows the PORT lamps to be switched between indicating LINK/ACT-SPEED, STATUS, or VLAN. | |
| Operating temperature | 0 to 40°C | 0 to 40°C | 0 to 40°C | |
| Storage temperature | -20 to 60°C | -20 to 60°C | -20 to 60°C | |
| Power supply (AC IN inlet) | AC100V-240V, 50/60Hz, Internal power supply (no power switch), Power supply inlet: locking type | AC100V-240V, 50/60Hz, Internal power supply (no power switch), Power supply inlet: locking type | AC100V-240V, 50/60Hz, Internal power supply (no power switch), Power supply inlet: locking type | |
| Power supply (EXT DC INPUT inlet) | External power supply requirements: 24VDC±2V, 1A, XLR-4-32 type Connector | External power supply requirements: 24VDC±2V, 1A, XLR-4-32 type Connector | External power supply requirements: 24VDC±2V, 1A, XLR-4-32 type Connector | |
| Maximum power consumption | 16 W, 0.29 A | 11 W, 0.21 A | 11 W, 0.21 A | |
| Heat dissipation | 14.0 kcal/h | 9.5 kcal/h | 9.5 kcal/h | |
| Chassis | Metal case, no fan | Metal case, no fan | Metal case, no fan | |
| Hazardous substances management | RoHS compliant | RoHS compliant | RoHS compliant | |
| Dimensions | W | 480mm | 480mm | 480mm |
| H | 44mm | 44mm | 44mm | |
| D | 362mm | 362mm | 362mm | |
| Weight | 4.6 kg | 4.2 kg | 4.2 kg | |
| Accessories | Power cord, Owner's manual | Power cord, Owner's manual | Power cord, Owner's manual | |
| Options | MMF-SWP1 (Optical expansion unit), PA-700 (AC adaptor) | MMF-SWP1 (Optical expansion unit), PA-700 (AC adaptor) | MMF-SWP1 (Optical expansion unit), PA-700 (AC adaptor) | |
