Description
Ubiquiti UniFi Video Camera G6 Entry
An intelligent door entry system with native UniFi Protect and UniFi Access integration.
Technical Specifications
Physical & Mechanical
-
Dimensions: 176 x 45 x 29.6 mm (6.9 x 1.8 x 1.2")
-
Weight: 275 g (9.7 oz)
-
Enclosure Material: Aluminum
-
Mounting: Wall mount, Gangbox mount plate, 20° wedge mount (Included); Junction box (Optional)
-
Mounting Materials: * Wall/Wedge mount: Aluminum/Stainless steel
-
Gangbox plate: SGCC steel
-
Gangbox cover: Polycarbonate
-
-
Weatherproofing: IP55
-
Tamper Resistance: IK07
Video & Optics
-
Main Camera: 5MP CMOS Sensor (1920 x 2560, 3:4)
-
Package Camera: 8MP CMOS Sensor (3264 x 2448, 4:3)
-
Max Frame Rate: 30 FPS (Main) / 3 FPS (Package)
-
Field of View (Main): H: 100°, V: 135°, D: 180°
-
Field of View (Package): H: 66°, V: 51.7°, D: 78°
-
Night Vision: IR LED illumination with IR cut filter (5 m / 16 ft range)
-
Image Settings: HDR, Color, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, NR by motion, masking, text overlay.
Hardware & Connectivity
-
Processor: Quad-core Arm® Cortex®-A53
-
Networking Interface: GbE RJ45 port
-
Connectivity: BLE 4.1, NFC
-
Power Method: PoE+
-
Supported Voltage Range: 42—57V DC
-
Max. Power Consumption: 16W
-
LEDs: R/G/B/W
Features & Access Control
-
Access Methods: NFC Card, Keyfob, Apple/Google Wallet, Mobile Unlock
-
Audio: Two-way intercom with integrated doorbell access
-
Smart Detections: People, Vehicles, Animals
-
Security: Face Recognition, NDAA Compliant
-
Software Support: UniFi Protect, UniFi Access
Environmental & Certifications
-
Operating Temperature: -30 to 50° C (-22 to 122° F)
-
Operating Humidity: 5 to 90% noncondensing
-
Certifications: CE, FCC, IC
