TOA SR-FB4 Rigging Bar for Type S Speaker
Product Details
The TOA SR-FB4 is the rigging bar for suspending Type S line array modules. It fits the SR-S4L and SR-S4S.
It will fly up to three speakers when they are joined with SR-EP4 extension plates — the largest array in the Type S range. Rigging at that scale is a structural question as much as an audio one: three modules is 48 kg of speaker before the hardware.
Supplied with: Suspension bracket mounting screws, M8 upset head × 6 | speaker mounting screws, M5 upset head × 8 | suspension bracket assembling screws × 2 | suspension bracket assembling washers × 1 set. Material and finish: Steel plate, white, paint.
Features
- Rigging bar for suspending Type S line array modules
- Flies up to three speakers joined with SR-EP4 plates
- Fits the SR-S4L and SR-S4S
- Full screw and washer set included
- 2.9 kg including accessories
Specifications
| Technical | |
|---|---|
| Product Type | Rigging Bar |
| Compatible Speakers | SR-S4L and SR-S4S |
| Material and Finish | Steel plate, white, paint |
| Included | Suspension bracket mounting screws, M8 upset head × 6 | speaker mounting screws, M5 upset head × 8 | suspension bracket assembling screws × 2 | suspension bracket assembling washers × 1 set |
| Physical | |
|---|---|
| Dimensions | 168 (W) × 170 (H) × 284 (D) mm, complete assembly |
| Weight | 2.9 kg (6.39 lb), including accessories |
| Color | White |
Specifications subject to change.
