Russound D1675 D-Series 16-Channel Digital Amplifier

Product Details

The Russound D1675 is a low-profile, high-performance Class-D amplifier built for versatility and power. Whether driving high-end home theater systems or powering multi-room audio setup across large spaces and outdoor zones, the D1675 offers flexible, high-fidelity sound distribution.

Features

• Powerful 16-Channel Amplification: Delivers up to 75 watts per channel at 4 ohms.

• Flexible Audio Routing: Features 3 input options per channel—2 shared bus inputs and 1 dedicated line input for maximum source versatility.

• Selectable Audio Filters: Easily configure each zone for Full Range sound, Low Pass (20Hz–160Hz), or High Pass (80Hz–20kHz) filtering.

• Bridgeable Channels: Inputs can be bridged to supply extra power where needed.

• Smart Power Control: 3 turn-on modes including Always On, Auto Signal-Sensing, and 12V Trigger Control.

• Space-Saving Design: Slim 2U rack-mountable profile with a clean industrial look.

Specifications

• Channels: 16

• Power Output (4Ω): 75W / Channel

• Power Output (8Ω): 37W / Channel

• Power Output (8Ω Bridged): 150W

• Frequency Response: 20Hz – 20kHz (+/-3dB)

• Signal-to-Noise Ratio: >90dB (A-weighted)

• Dimensions: 17.125" W x 3.5" H x 9.75" D (43.5 x 8.8 x 24.8 cm)

• Weight: 12.8 lbs (5.8 kg)

• Warranty: 2-Year Limited

What’s in the Box

• Russound D1675 Amplifier

• 6-foot Power Cord

• Set of Removable 4-pin Speaker Connectors

• Rack Mount Ears with Screws

• Owner's Manual
