Description
Onkyo Muse Y-50 Network Streamer & Integrated High-Power Amplifier
Product Details
The inspiring Onkyo Muse Y-50 fuses 80 years of Japanese audio expertise into an elegant, 250W hi-fi hub with premium design, smart features, and versatile connectivity.
Specifications
| Category | Specification | Detail |
| Features & Connectivity | Custom App | Onkyo Control |
| Room Calibration | Onkyo Room EQ | |
| Analog Audio Input | RCA (Unbalanced) x 3 pair | |
| Digital Audio Input | HDMI IN x 1 (HDCP2.3, 4K/120p, 8K/60p, VRR, QFT, ALLM, QMS, SBTM, DSC, HDR10+, Dolby Vision), HDMI ARC, COAX x 1, Optical x 1, USB-A (Storage playback) x 1 | |
| HDMI Output | 1 | |
| Phono Input | 1 pair (MM/MC) | |
| Audio Pre Output | RCA (Unbalanced) x 1 pair | |
| Subwoofer Output | 1ch | |
| Headphone Output | 1/4” (6.3mm) Jack x 1 | |
| Network Connectivity | Wi-Fi, Ethernet Terminal (10BASE-T/100BASE-TX) | |
| Bluetooth | SBC, AAC | |
| Network Service | Spotify Connect, TIDAL Connect, Qobuz Connect, AirPlay, Google Cast, Music Server | |
| Audio Performance | Output Power (U.S.A.) | 125W (FTC, 8Ω, 20Hz - 20kHz, THD 0.08%, 2ch driven) / 250W (4Ω, 1kHz, THD 0.7%, 2ch driven) |
| Output Power (EMEA/APAC) | 250W (4Ω, 1kHz, THD 0.7%, 2ch driven) / 125W (8Ω, 20Hz-20kHz, THD 0.08%, 2ch driven) | |
| Amplifier Channel | 2ch | |
| Pre Amplifier Channel | 2.1ch | |
| Amplifier Type | Class D | |
| Frequency Response | 20Hz ~ 30kHz (+1/-3dB) | |
| Tone Control (Bass/Treble) | 100Hz ±10dB / 10kHz ±10dB | |
| Speaker Impedance | 4 - 16Ω | |
| General | Product Dimensions (W x H x D) | 350 x 99 x 337 mm (13.8 x 3.9 x 13.3 inches) |
| Product Weight | 4.9 kg (10.8 lbs) | |
| Package Dimensions (W x H x D) | 465 x 225 x 405 mm (18.3 x 8.9 x 15.9 inches) | |
| Package Weight | US: 7.2 kg (15.9 lbs) / EMEA: 7.6 kg (16.8 lbs) | |
| Standby Power Consumption | Less than 0.4W (Standby) / Less than 1.8W (Network Standby) | |
| Power Consumption | 120W | |
| AC Voltage | AC 100-240V, 50Hz/60Hz |
