| PREAMPLIFIER SECTION |
|
|
| Line Input, Pre-Out (Analog Bypass On) |
THD (20 Hz – 20 kHz) |
<0.005 % at 4V out |
|
Signal-to-Noise Ratio |
>90 dB (IHF, A-weighted, 500 mV out, unity gain) |
|
Input impedance (R and C) |
28 kohms + 360 pF |
|
Maximum input signal |
>5.7 Vrms (0.1 % THD) |
|
Output impedance |
345 ohms |
|
Input sensitivity |
100 mV (500 mV out, Volume maximum) |
|
Frequency response |
20 Hz – 20 kHz (±0.3 dB) |
|
Maximum voltage output |
>5 V (0.1 % THD) |
| Line In, Headphone Out |
THD (20 Hz – 20 kHz) |
<0.005 % at 1V out |
|
Signal-to-Noise Ratio |
>90 dB (32 ohms load, A-weighted, 1V out, unity gain) |
|
Frequency response |
20 Hz – 20 kHz (±0.3 dB) |
|
Channel separation |
>60 dB at 1 kHz |
|
Output impedance |
22 ohms |
| GENERAL SPECIFICATIONS |
|
|
| Line In, Speaker Out |
Continuous output power into 8 ohms and 4 ohms |
50 W (20 Hz – 20 kHz at rated THD, both channels driven) |
|
THD (20 Hz – 20 kHz) |
<0.03 % (250 mW to 50 W, 8 ohms and 4 ohms) |
|
Signal-to-Noise Ratio |
>90 dB (A-weighted, 500 mV input, 1 W out in 8 ohms) |
|
Clipping power |
>70 W (1 kHz 0.1 % THD, 4 ohms)
>55 W (1 kHz 0.1 % THD, 8 ohms)
|
|
IHF dynamic power |
8 ohms: 120 W
4 ohms: 250 W
2 ohms: 390 W
|
|
Peak output current |
>16 A (1 ohm, 1 ms) |
|
Damping factor |
>52 (20 Hz to 6.5 kHz, 50 W, 8 ohms) |
|
Frequency response |
20 Hz – 20 kHz (±0.3 dB) |
|
Channel separation |
>75 dB (1 kHz)
>70 dB (10 kHz)
|
|
Input sensitivity (50 W in 8 ohms) |
750 mV |
|
Frequency band |
2.402 G – 2.480 G |
|
Maximum transmit power |
7 dBm ± 2 dBm |
|
Power consumption, standby mode* |
0.5 W |
| Line In, Phono Input |
THD (20 Hz – 20 kHz) |
<0.05 % at 50 W out |
|
Signal-to-Noise Ratio |
>82 dB (10 mV in, A-weighted, 1 W out) |
|
Input impedance (R and C) |
46 kohms / 100 pF |
|
Input sensitivity |
1.6 mV (20 Hz – 50 W out, Volume maximum) |
|
Frequency response |
20 Hz – 20 kHz (±0.3 dB)
(Note: The RIAA response is consistent with a pre-emphasis that is rolled off at 50 kHz by a second order filter, such as used in Neumann cutting lathes.)
|
|
Maximum input signal at 1 kHz |
>15 mVrms (0.1 % THD) |
| DIMENSION AND WEIGHT |
Gross dimensions (W x H x D) ** |
356 x 129 x 329 mm
14 1/8 x 5 1/8 x 13 inches
|
|
Net weight |
5.8 kg (12.8 lbs) |
|
Shipping weight |
7.2 kg (15.9 lbs) |
| BLUOS SPECIFICATIONS |
|
|
| BluOS Audio |
Supported audio file format |
MP3, AAC, WMA, OGG, WMA-L, ALAC, OPUS |
|
Supported high-resolution audio file format |
FLAC, MQA, WAV, AIFF |
|
Sampling rate |
up to 192 kHz |
|
Bit depths |
16 – 24 |
| BluOS Supported Services* |
Music Services |
Click here |
|
Internet Radio |
Click here |
|
Integration partners |
Control4, Crestron, ELAN, Lutron, Push, Roon, RTI, URC |
|
Voice Control |
Skills and support for Amazon Alexa and Apple’s Siri with corresponding enabled devices and App |
| BluOS Connectivity |
Network connectivity |
Gigabit Ethernet RJ45
Wi-Fi 5
|
|
Supported network file share protocol |
Server Message Block (SMB) |
|
Bluetooth quality |
aptX HD 5.0 |
|
Bluetooth connectivity |
Receive Mode (Playback from BT devices) |
