Beale Street Audio 220W/120W Sub Amp

• Amp Type – High Efficiency Class D
• Power – 1×120 watt Subwoofer Amplifier – 4 Ohm stable
• Variable Crossover – 40-160 Hz
• Highlights – Compact Chassis
• Maximum Output Power – 80W/8Ω; 120W/4Ω
• THD – <1%
• Frequency Response – 20Hz-160Hz +/-1dB
• Signal to Noise – 95dB
• Input Sensitivity – 200mV
• THD – <1%
• Phase – 0-180°
• Signal to Noise – 95dB
• Input – RCA
• Speaker Level Input/Output
• Trigger Input – +12VDC to +24VDC
• Line Voltage Power – 110-120/220-240 VAC
• Standby Power – 1.8W
• Maximum Power Consumption – 150W
• Dimensions – 5.7”W x 1.8”H x 5” D (143mm W x 45mm H x 125mm D)
• Overall Length – 5.9” (150mm) (including knobs/connectors)
• Weight – 1.75lbs (0.79kg)

Downloads

A120 Product Manual
