Description
Ajax 42800.13.WH3 DoorProtect Plus (9NA) UPC white
Product Details
DoorProtect Plus Jeweller is a wireless opening detector that adds a built-in accelerometer to the reed switch, so it reports not only an opening but also a blow to the door or window and a change in the leaf's angle. That covers the burglar who breaks the glass or levers the frame instead of opening it.
The reed switch sits in a sealed plastic capsule with chatter protection. Shock sensitivity has three adjustable levels with an option to ignore a single isolated impact, and the tilt sensor triggers anywhere from 5° to 25° of movement. Jeweller radio reaches up to 3,900 ft in open space and the pre-installed CR123A battery lasts up to 5 years.
Two magnet sizes ship in the box for narrow and standard frames, and terminals accept a third-party wired detector with a normally closed (NC) contact. Tilt detection makes it the right choice for vaults, display cases, roller shutters and gates, where the threat is the panel being moved rather than opened. The SmartBracket panel lets an installer mount the device on the wall without disassembling the enclosure, and the detector pairs with the hub by scanning a QR code. Correct installation at a height of 2.4 m with the lens perpendicular to the likely intrusion path is what delivers the stated detection pattern and pet immunity. It can be reconfigured remotely from the Ajax apps without a site visit. Supplied in the white finish. The same device in black is stocked as 42799.21.BL3.
Features
- Wireless opening detector with shock and tilt detection
- Built-in accelerometer alongside the reed switch
- Shock sensitivity: 3 adjustable levels
- Option to ignore a single isolated shock
- Tilt sensor activation threshold adjustable from 5° to 25°
- Protection against reed switch chattering
- Two magnet sizes included for narrow and standard frames
- Chime feature when the system is disarmed
- Input for a third-party wired detector with NC contact type
- Up to 5 years on the pre-installed CR123A battery
- Up to 3,900 ft radio range with an Ajax hub or range extender
- Jeweller encrypted two-way radio with frequency hopping
- Tamper alarm and device authentication against spoofing
- SmartBracket mounting panel — no enclosure disassembly
- Available in white and black glossy finishes
Specifications
| Technical | |
|---|---|
| Sensitive Elements | 1 × accelerometer, 1 × reed switch |
| Shock Sensitivity | 3 levels, adjustable by a PRO or admin |
| Option to Ignore Single Shock | Available |
| Tilt Sensor Activation Threshold | From 5° to 25°, adjustable |
| Input for Additional Detector | Third-party wired detector with NC contact type (UL certified) |
| Chime | Yes, when the system is disarmed |
| Communication Technology | Jeweller — proprietary two-way wireless protocol for commands, alarms and events |
| Frequency Bands | 866.0–866.5 MHz | 868.0–868.6 MHz | 868.7–869.2 MHz | 905.0–926.5 MHz | 915.85–926.5 MHz | 921.0–922.0 MHz (region-dependent) |
| Maximum Effective Radiated Power (ERP) | Up to 20 mW |
| Radio Signal Modulation | GFSK |
| Radio Communication Range | Up to 3,900 ft (open space) |
| Encrypted Communication | Block encryption with dynamic key |
| Frequency Hopping | Yes, to prevent radio interference and jamming |
| Tamper Alarm | Notifications on detachment or removal attempts |
| Protection Against Spoofing | Device authentication at each communication session |
| Communication Loss Detection | After 36 s (3 data packages in 12 seconds) |
| Physical | |
|---|---|
| Battery | 1 × CR123A (pre-installed), type C |
| Battery Manufacturer | Huiderui (UL listed) |
| Nominal Operating Voltage | 3 V DC |
| Current Consumption | Quiescent: 11.8 μA | Maximum: 24 mA |
| Full Battery Capacity | 1,600 mAh |
| Low / Recovery / End-of-Life Battery Voltage | 2.5 V DC / 2.7 V DC / 2.1 V DC |
| Calculated Battery Life | Up to 5 years |
| Dimensions | Ø 0.79″ × 3.54″ |
| Weight | 1.02 oz |
| Operating Temperature Range | 14 °F to 104 °F |
| Operating Humidity | Up to 75% |
| Protection Class | IP50 |
| Colors | White, Black |
| Complete Set | DoorProtect Plus Jeweller, SmartBracket mounting panel, CR123A battery (pre-installed), big magnet, small magnet, terminal to connect a third-party detector, installation kit, quick start guide |
| Warranty | 24 months |
Specifications subject to change.
